2. UI operation
2.1 Description of Washer
No
Product
current state
Description
1 Power off
Power is NOT connected。
2 Standby
Only turn on the machine，without any button operation, all displays and loads
are turned off.
3 Set In standby mode, turn on the power button to enter the program setting mode.
4 Running
When finished setting process, press “Start/Pause” button and the program
enters the operation mode.
5 Pause
While the program is running, press the “Start/Pause” button, the program
enters the pause mode, and closes all outputs.
6 StartDelay Reserve program completion time
7 Alarm When the PCB detects a fault, it makes alarm and displays
8
Maintenance
mode
Used for factory inspection or fault diagnosis
2.2 Program Function table
Whirlpool Essential TRS
Generic function
Additional Function
power-off
Finish
sound
cancellation
Anti-
wrinkle
Time wash
Childlock
Dry（only combo）
Mixed
★
● ● ● ●
●
Quick
● ● ● ●
○
Wash&dry60′
● ○ ○ ●
○
Gentle
● ● ● ●
●
Spin
● ● ● ●
●
Stain
● ● ○ ●
●
Eco cotton
● ○ ○ ●
●
Wool
● ● ● ●
●
Hot air refresh
● ○ ○ ●
○
Allergy care
● ● ●
○
Sanitize wash
● ● ● ●
●
Drum clean
● ○ ○ ●
●
Note: 1. “○” indicates the function is unavailable. “●” indicates that the function is optional. “★” indicates that the function
2.3 Key Functions
whirlpool-combo：power、Start / Pause、Time wash、Dry、Speed、Rinse、Temp、Program；
whirlpool-washer：power、Start / Pause、Time wash、Anti wrinkle、Speed、Rinse、Temp、Program；
No Buttons
Product initial
state
Product
current
state
Operation and display
1 Power Standby Standby
Turn off the washing machine and turn off all displays
Set Set
Running Running
Pause Pause
Reservation Reservation
Alarm Alarm
Maintenance mode
Maintenance
mode
See the inspecting specifications of the base board for
details.
2 Start / Pause
Standby Standby
No response.
Set Running The selected program starts immediately
Running Pause
Pause
Pause
Status
before pause
Press to continue the process before halt.
Spinning stage: begin at the clothing adjustment phase
Other stages: continue the action before halt
Reservation Reservation Washing reservation
Alarm Running
Cancel the alarm, continue the action before alarming.
