36
C Use a vice to remove the circlip
on
the water inflow hose. Cut off the
harness tie. Unplug the harness.
Remove the inflow hose and inflow
pipes. Remove the inflow box and
inflow valve assembly.
If unnecessary to remove the part as
shown in Figure C, do not dismantle
it. It is dif
ficult to seal again after
dismantling.
D. Pick up the water inflow box. Open
the 6 snaps around the inflow box to
take down the sprinkler.
