38
10 Upper counterweight and front
counterweight
A Use a special tool to remove the
three screws as shown in picture to
remove the upper counterweight and
the front counterweight.
11. Drying duct
A. Remove 5 tightening screws shown
in the picture.
B Remove the other fastening screw at
the clamp which connects the lower
part of the drying duct with the outer
drum.
C Cut off the front hose tie and
remove the hose.
Make sure the power
plug is removed before
doing this.
