35
7. Door lock
Remove the 2screws that secure the
door lock on the front cover. Then the
door lock can be removed.
8. Water inflow box and valve
assembly
A Remove the tightening screws for
the valve and the water inflow box
assembly on the back of the cabinet.
B. Remove the screw shown in the
figure.
To Next Page
