Whirlpool GY396LXP - Control Panel Parts

CONTROL PANEL PARTS
2
For Models: GY396LXPB03, GY396LXPQ03, GY396LXPT03, GY396LXPS03
(Black) (White) (Biscuit) (Stainless)
W10129038
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Control Panel
W10036010 Black
W10036000 White
W10035990 Biscuit
W10035980 Stainless
2 Switch, Infinite
9750638 LR, RF
9750639 RR
9750641 LF
3 9757476 Control, Migration
4 9757119 Bracket, Console
5 3196068 Lens, Indictor (2)
6
W10036100 Bracket, Oven
Control
7 8523265 Housing, Indicator
Light (2)
8 Endcap
Right
9756611BL Black
9756611WH White
9756611BT Biscuit
Left
9756614BL Black
9756614WH White
9756614BT Biscuit
9 Knob
9756659BL Black
9756659WH White
9756659BT Biscuit
10 3196537 Screw
11 9780271 Screw
12 311865 Screw
13
W10078570 Membrane, Switch
Assembly
