Whirlpool Maytag - Connect Drain Hose

18
Loosen bolts with a 5/8" (16 mm) wrench. Slide each bolt
and spacer to center of hole. Pull bolts and plastic spacers
from back of washer. Discard bolts and spacers.
IMPORTANT: Do not plug washer in until installation has
been completed.
3. Remove transport bolts from
washer
CONNECT DRAIN HOSE
If clamp is not already in place on elbow end of drain hose,
squeeze clamp with pliers and slide it over end of hose,
centering it between the ribs, as shown. Squeeze clamp
with pliers and slide elbow end of drain hose onto drain
port and secure with clamp.
For a laundry tub or standpipe drain, go to step 6.
For a oor drain, remove the preinstalled drain hose form
as shown in Step 5. You may need additional parts with
separate directions. See “Alternate Parts.”
It is the responsibility of the installer to install and secure the
drain hose into the provided plumbing/drain in a manner that
will avoid the drain hose coming out of or leaking from the
plumbing/drain.
4. Attach drain hose to drain port
Ribs
2. Locate transport bolts
Locate four transport bolts on rear of washer.
