31
COIL ELEMENTS AND REFLECTOR BOWLS
(MODELS RF360BXE AND RF360PXE) (CONT.)
Replacing
1. Make sure all coil elements are off and cool
before replacing coil elements and reflector
bowls.
2. Line up openings in the reflector bowl with the
coil element receptacle.
3. Hold the coil element as level as possible with
the terminal just started into the receptacle. Push
the coil element terminal into the receptacle.
4. When the terminal is pushed into the receptacle
as far as it will go, push down the edge of the
coil element opposite the receptacle.
BAKE
OFF
BAKE
CARING FOR YOUR RANGE
continued on next page
