Whirlpool RF385PXG - Coil Elements and Reflector Bowls

31
CARING FOR YOUR RANGE
COIL ELEMENTS AND REFLECTOR BOWLS (MODELS RF
3
8
5
PXG AND RF
3
8
7
LXH)
Replacing
1. Make sure all coil elements are off and cool
before replacing coil elements and reflector
bowls.
BAKE
OFF
BAKE
3. Pull the coil element straight away from
the receptacle.
4. Lift out the reflector bowl. See the “Cleaning
chart” earlier in this section for cleaning
instructions.
2. Push in the edge of the coil element, opposite
the receptacle. Then lift it just enough to clear
the reflector bowl.
BAKE
OFF
BAKE
Removing
1. Make sure all coil elements are off and
cool before removing coil elements and
reflector bowls.
continued on next page
