Whirlpool W5WCE065XW0 User Manual

6-1
Refrigerant System
Diagrams
HOT DISCHARGED AIR
OUTDOOR COILS
AXIAL FAN
COMPRESSOR
REFRIGERANT FLOW DIRECTION
CAPILLARY
CENTRIFUGAL
OR CROSS FAN
INDOOR COILS
COOLED AIR
All Models use R-410A refrigerant. R-410A operates at higher pressures and temperatures than
R-22 units and requires dedicated sealed system equipment.
Note: Do not aempt sealed system entry or service unless you have been trained on servicing
R410-A systems and have the proper equipment.

Whirlpool W5WCE065XW0 Specifications

General

Brand	Whirlpool
Model	W5WCE065XW0
Type	Window Air Conditioner
Room Size	Up to 250 sq. ft.
Energy Efficiency Ratio (EER)	11.0
Voltage	115V
Fan Speeds	3
Cooling Settings	3
Filter Type	Washable
Installation Type	Window
Noise Level	52 dB
Cooling Capacity	6000 BTU
