Whirlpool WFC 3C26 - Technical Memo: Door Removal - CCU; CCU Locks and Terminal Disconnection

TECHNICAL MEMO
Removing the door hinged.
*Figure show an exploded
view of the base.
4 - This set of wire/terminal is the connection between the CCU and the
door. Remove the terminal by pulling (Be careful and keep in mind about the
lock of the terminal.)
1-2-3 Open the locks
of the CCU.
