DETAILED PLANNING DIMENSION
WHIRLPOOL
®
FRONT LOAD WASHER WITH LOAD & GO
™
DISPENSER - 4.5 cu ft
3 of 15
IMPORTANT: Dimensional specications are provided for planning purposes only.
PRODUCT DIMENSIONS
WFW5620HW 4.5 cu ft DOE (US)/5.2 cu ft IEC (CAN)
Unit of Measurement in (minimum) mm (minimum) in (maximum) mm (maximum)
Door Width (C) 25
11
∕
16
652 - -
Product Depth (D) 31
9
∕
16
802 - -
Product Depth with Door
Open (E)
54
7
∕
8
1393 - -
Door Height (F) 25
11
∕
16
652 - -
Height to Bottom of Door (G) 9
1
∕
2
241 - -
SIDE VIEW
C
F
G
E
D

Whirlpool WFW5620HW Specifications

General

Style	front load
Color	white
Washer Capacity	4.5 cu. ft.
Number of Cycles	14; 37
Temperature Settings	5
Internal Heater	yes
Control Panel	touchpad
Cycle Signal	yes
Steam	yes
Add Wash	yes
Soak Settings	yes
Wi-Fi	no
Voltage	120 volts
Current	15a

Weight and Dimensions

Depth	31 9/16 inch
Height	38 5/8 inch
Width	27 inch
