Whirlpool WHB27S - Page 7

4
1
2
3
6
8
5
7
Top hinge cover
1
Top hinge screw
2
Top hinge
3
Cabinet plug
4
Bottom hinge
5
Bottom hinge screw
7
Leveling legs
8
Door handle plug
6
NOTE:
1. Remove top hinge cover and 3 top hinge screws which are below it. Then
remove top hinge.
2. Remove 1 cabinet plug and 1 door handle plug.
3. Remove the door.
4. Remove right and left leveling legs.
Do not tilt the appliance over 45 degree when reversing the door as
possible damage to the sealed system may occur.
10
11
MOVING THE BEVERAGE CENTER
6.
,
1. Turn off the beverage center and unplug from the outlet.
2. Remove all and securely tape down all loose items inside.beverage
3. Tape the door shut.
4.
5.
Excessive Weight Hazard
Use two or more people to move and install beverage center.
Failure to do so can result in back or other injury.
WARNING
WARNING
Explosion Hazard
Risk of fire or explosion due to puncture of refrigerant
tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
