Whirlpool WSN11W - Product; Characteristic of Thermostat; Electrical Parts

Ref. No. : SM77-05-058-0 Printed : Nov’2005
Page : 2
1-2) Product
Model WSN11W
Classification 2 Doors No Frost
Temperature Control Thermostat Electronic
Defrost System Automatic
Drain Automatic (Heat by transfer from the compressor)
Evaporator Aluminum Coil With Bond
Condenser Copper Tube Inside
Cabinet Rigid Polyurethane Foam (HCFC-141b)
Freezer Door Rigid Polyurethane Foam (HCFC-141b)Insulation
Refrigerator Door Rigid Polyurethane Foam (HCFC-141b)
Refrigerant HFC-134a
Refrigerant Charge (g.) 105
Overall Dimension (WxDxH (mm.)) 606 x 670 x 1,522
Packing Dimension (WxDxH (mm.)) 657 x 749 x 1,635
Net Weight (kg.) 65.0
Gross Weight (kg.) 65.0
1-3) Characteristic of Thermostat
Operating Temperature (°C) 1013hPa (mb)
Model MM1-8612
Dial Position ON OFF
WARM
°C-3 ± 3
-
NORMAL
°C-9 ± 1.1 -18 ± 1.1
Temperature
Control
COLD
°C
-
-25 ± 2.2
1-4) Electrical Parts
1-4-1) MODEL WSN11W
Model C-BZN152L6Z
Compressor
Power Supply Range
220V / 50 Hz
Starting Relay PTH7M220MC1
Overload Protector 4TM734RHBYY-53
Starting Capacitor -
Running Capacitor -
Interior Light 240 V / 15 W
