5
2. Prepare the washer
Washer
bottom
Partially install two of the #12 x 3/4"
hex-head sheet metal screws in the
indicated holes. Leave a space of
about 3/8" (10 mm) between the
screw head and the bottom of
the washer.
NOTE: If your washer has leveling feet installed, remove them.
1. Place washer on its side
Pedestal box
Drawer divider
To avoid oor damage and ease installation and handling,
unfold the empty pedestal box at and place it next to the
washer. Position the drawer divider so that it will be near the
top of the washer, as shown. Gently tip the washer on its side
so the washer is resting on the drawer divider.
3. Attach pedestal to washer
Move the pedestal against the washer bottom. The front of
the pedestal cabinet should align with the washer cabinet
as shown below.
Slide the pedestal’s keyhole slots over the lower two partially
installed screws.
Pedestal Washer
Front
View from above
