8
3. Adjust pedestal feet
4. Securely tighten jam nuts
2. Place drawer divider in drawer
Hex-head screw
Drawer slide
1. Reassemble pedestal drawer
2. Check levelness of washer/dryer
Place level here
Place a level on top edges of
washer/dryer, checking each side
and front. Rock washer/dryer back and forth to make sure all
four feet make solid contact with oor.
If not level, adjust pedestal feet up or down, repeating as
necessary.
Locate the 1/4" hex-head screws on the top of each pedestal
foot. Reach inside the pedestal and use a 1/4" hex-head
ratchet or open-end wrench to adjust the feet up or down
as needed, to level the washer/dryer.
NOTE: Make sure all four pedestal feet are in solid contact
with the oor.
When the washer/dryer is level, use a 9/16" open-end wrench
to securely tighten all four jam nuts against the pedestal.
IMPORTANT: The jam nuts must be tightened to avoid
vibration.
Reinstall pedestal drawer
Pull both drawer slides out and reassemble the drawer to
the drawer slides with the two hex-head screws.
Remove the shipping lm from the drawer.
Place the divider in the drawer at the desired
location. Close the drawer.
NOTE: Use of the divider is optional.
Not Level LEVEL Not Level
