White 550 - Page 17

17
Ref.
No.
Part No. Part Description
1.
618-0123 RH Housing
2.
618-0418 LH Housing w/Fitting
3.
710-0642 Self Tapping Screw, 1/4-20 x .75
4.
711-1020
711-0908
Spiral Axle, 22” (550)
Spiral Axle, 24” (750)
5.
714-0161 Hi-Pro Key, 3/16 x 5/8
6.
715-0143 Spring Spirol Pin, .25 x 1.25
7.
717-0528 Worm Gear, 20-tooth
8.
717-0526 Worm Shaft
9.
718-0186 Thrust Collar
10.
721-0325 Grease Plug
11.
721-0327 Grease Seal
12.
736-0351 Flat Washer, .76 x 1.5 x .030
13.
736-0369 Flat Washer, .508 x 1.0 x .020
14.
736-0445 Flat Washer, .76 x 1.5 x .060
15.
741-0662 Flange Bearing, .75 x 1.0 x .59
16.
741-0663 Flange Bearing, .503 ID x .75 OD
17.
618-0413
618-0414
Gear Assy Complete, 22” (550)
Gear Assy Complete, 24” (750)
18.
737-3000 Grease Fitting, 3/16” Drive
— 737-0168 Grease (Two Ounces)
Models 550 & 750
2
12
4
6
7
10
9
14
11
8
16
1
3
15
5
13
3
17
18
