White 550 - Page 19

19
Models 550 & 750
Ref.
No.
Part No. Part Description
1.
710-1652 Hex Screw
2.
784-5688 Drive Cable Guide Bracket
3.
784-5687 Auger Clutch Cable Bracket
4.
756-0625 Roller Cable
5.
738-0924 Hex Screw 1/4-28
6.
684-0030 Frame Assembly
7.
741-0563 Ball Bearing
8.
736-0105 Bell Washer
9.
712-0116 Lock Jam Nut
10.
741-0598 Hex Flange Bearing
11.
736-0188 Flat Washer
12.
784-5689A Front Support Guide Bracket
13.
710-0538 Lock Hex Screw
14.
736-0242 Bell Washer .340 ID x .872 OD
15.
714-0474 Cotter Pin
16.
736-0160 Flat Washer .536 ID x .930 OD
17.
710-0788 Hex Washer Screw 1/4-20
18.
784-5590 Frame Shift Bracket
19.
784-5638 Frame Cover
20.
710-0599 Hex Washer Screw 1/4-20
21.
736-0351 Flat Washer .760 ID x .50 OD
22.
717-1445 Gear
23.
714-0126 Key
24.
717-1444 7-Tooth Shaft
25.
715-0249 Roll Pin
26.
714-0143 Clik Pin
27.
684-0042B Friction Wheel Assembly
28.
656-0012A Friction Disc Wheel
29.
684-0013B Wheel Shift Rod Assembly
30.
746-0897 Drive Cable
31.
748-0190 Spacer
32.
684-0021 Friction Wheel Bracket Ass’y
33.
732-0264 Extension Spring
34.
712-0711 Jam Nut, 3/8-24
35.
746-0898 Drive Cable
36.
738-0869 Axle
37.
717-1445 Gear
38.
714-0126 Key
39.
717-1444 7-Tooth Shaft
40.
618-0063 Friction Wheel Bearing
41.
734-1732
734-1859
Tire Only, 13 x 4 (550)
Tire Only, 15 x 5 (750)
42.
741-0401 Sleeve Bearing
43.
734-0255 Air Valve
44.
634-0114
634-0140
Wheel Assembly (550)
Wheel Assembly (750)
(Incl. Ref. 41, 42, & 43)
Ref.
No.
Part No. Part Description
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Oyster Gray, the part number to
order would be 700-xxxx-0662.
Oyster Gray: 0662
Powder Black: 0637
