PETS-2 Crossing Telephone System
QUICKFIX INSTALLATION HANDBOOK
38
From Colour To
- 2, 8b GREEN – Yellow - 7
- 2, 9a YELLOW – Brown - 8
- 2, 9b BROWN – Yellow - 9
- 2, 0a YELLOW – Grey - 10
- 2, 0b GREY – Yellow - 11
Jumpers
From Colour To
Block 2, 1a GREEN – Red Block 1, 8b
Block 2, 1b RED – Green Block 1, 8a
Block 2, 6a BLUE - Yellow Earth post
Block 2, 6a BLUE - Yellow Block 2, 6b
Block 2, 4a WHITE – Blue Block 1, 8a
Telecommunications Connection Lead ( 10 pair )
From Colour To
Block 3, 1a Not connected to D
connector
Spare
- 3, 1b Not connected to D
connector
Spare
- 3, 2a Not connected to D
connector
Spare
- 3, 2b Not connected to D
connector
Spare
- 3, 3a WHITE – Green 25 way D pin 14
- 3, 3b GREEN – White - 15
- 3, 4a WHITE – Brown - 1
- 3, 4b BROWN – White - 2
- 3, 5a WHITE – Grey - 6
- 3, 5b GREY – White - 4
- 3, 6a RED – Blue - 3
- 3, 6b BLUE – Red - 5
- 3, 7a RED – Orange - 13
- 3, 7b ORANGE – Red - 25
- 3, 8a RED – Green - 11
- 3, 8b GREEN – Red - 12
- 3, 9a RED – Brown - 10
- 3, 9b BROWN – Red - 8
