Page 8 of 40
Issue 2
13/12/99
PETS-2 Crossing Telephone System
QUICKFIX INSTALLATION HANDBOOK
8
1 off PETS 2 Signal Box unit, with card removal ‘pullers’ (inside)
1 off Junction Box, complete with pre-wired connectorised leads.
1 off Installation Handbook (this book)
1 off 9 pin female ‘D’ connector (for the power supply lead)
1 off Earth lead - M6 ring terminal and 2 metre green/ yellow wire
2.2 Level Crossing Kit (WEL part A35155)
Upon opening the packaging, the contents should be checked to the following list:
1 off PETS 2 Level Crossing unit, with card removal ‘pullers’ (inside)
1 off Junction Box, complete with pre-wired connectorised leads.
1 off Installation Handbook (this book)
1 off 9 pin female ‘D’ connector (for the power supply lead)
1 off Earth lead - M6 ring terminal and 2 metre green/ yellow wire
3. ACCESSORIES
The following table provides information on the standard accessories available for use with
PETS 2:
WEL Part No. Signal Box Crossing Description
A33838 Note 2 Line Card - for local telephones. This Line card
is identical to the original PETS Line card; and
is also used on PETS 2 but within the Level
Crossing unit only.
A35173 Note 1 Line Card - Signalbox PETS2. This item is
different to the original due to a modified CALL
button arrangement.
A34566 (new
version from Q3
’98 - A35168)
Note 3 Note 3 Power supply and battery charger, batteries
not included.
A35166 Note 4 NA Remote Alarm Display Kit
A35169 Note 5 Note 5 Battery Set (4 off) 6Ahr
A35170 Note 5 Note 5 Battery Set (4 off) 12Ahr
A35171 Note 6 Note 6 Battery Set (4 off) 17Ahr
A35172 Note 7 Note 7 Firmware Upgrade (when applicable)
G42279 Note 8 Note 8 ‘Handbook for Design, Installation and
Maintenance’
G42279CD Note 8 Note 8 CD version of ‘Handbook for Design,
