Page 6 of 40
Issue 2
13/12/99
PETS-2 Crossing Telephone System
QUICKFIX INSTALLATION HANDBOOK
6
LIST OF FIGURES
FIGURE 1 - PHOTOGRAPH OF SIGNALBOX UNIT 11
FIGURE 2 - PHOTOGRAPH OF LEVEL CROSSING UNIT 13
FIGURE 3 - PHOTOGRAPH OF THE CARD FRAME 15
FIGURE 4 - CARD REMOVAL TECHNIQUE 17
FIGURE 5 - SIGNALBOX UNIT SHOWING LABEL INSERTS 25
FIGURE 6 - LEVEL CROSSING UNIT (FRONT PANEL EARTH TAG) 26
FIGURE 7 - INTERNAL LAYOUT - JUNCTION BOX 27
FIGURE 8 - POWER SUPPLY VOLTAGE SELECTOR (APPLICABLE TO SB & LC UNITS)31
