Whyte T-129 S - Page 16

Page 16
2016 Edition 1
WHYTE Service Manual
Item Description
1 M5 x 16mm long Socket-head Capscrew (T-25 Torx®)
2 Collar for M5 Capscrew
3 Hollow Pivot Pin Ø8mm x 31mm long
4 Flanged Nut M12 x 19mm long
5 Flanged Screw M12 x 15mm long
6 Rear Shock Absorber
8 M22 Bearing Cap (15mm A/F)
9 M8 Aerospace Nut (10mm A/F)
10 External M8 x 71mm long Stud
11 M6 x 20mm long Countersunk-head Capscrew (4mm A/F Internal Hex)
12 Collar for M6 Countersunk-head Capscrew
13 Internal M6 x 70mm long Hollow Pivot Pin
14 M8 x 23 long Flanged Screw (T-25 Torx®)
15 M8 x 20mm long Socket-head Capscrew (5mm A/F)
16 G-160 Main Frame
17 G-160 Right Seat-stay
18 G-160 Left Seat-stay
19 G-160 Chain-stays
20 75mm centres H-Link Assembly
7 Shock Extender
