Whyte T-129 S - 6.2 Stripping and Reassembling Bearings

Page 20
2016 Edition 1
WHYTE Service Manual
6.2: STRIPPING AND REASSEMBLING BEARINGS.
In the Whyte G-160 (Reference figures 9 & 10)
Figure 13: Assembly of 75mm H-Link
Item Description
1 KP5AX bearing
2 Shield washer (O.D. 17.5mm)
3 75mm centre-to-centre Alloy Quad-Link Body
