Wibrain B1E - Using Wired Network

A wired network is a network environment used for a company or broadband internet connection at home.
① Connect a LAN cable to the LAN port on the Desktop Cradle (Optional Item).
② Go to Start -> Control Panel -> Network and Internet Connection -> Network Connection
③ Right-click on Local Area Connection and select Properties.
④ Select Internet Protocol Version 4(TCP/IP) from the Networking tab and click Properties.
⑤ Configure the IP settings.
When using DHCP select Obtain an IP address automatically.
To use a static IP address select Use the following IP address and set the IP address manually.
⑥ When you have completed the settings, click the OK button.
The network settings are done.
Using both DHCP and a fixed IP simultaneously.
Using the Alternate Configuration provided by Windows XP you can set both automatic and fixed IP address or
choose to use either of them to connect to the Internet.
① Go to Start -> Control Panel -> Network and Internet -> Network Connection -> Local Area Connection
② Right-click on the Local Area Connection and select Properties.
③ Select Internet Protocol Version 4 (TCP/IP) from the Networking tab and select Properties.
④ Select the Alternate Configuration tab, select User configured and fill in the corresponding fields.
⑤ When you have completed the settings, click the OK button.
●
Using Wired Network
34
NOTE
■ The LAN device driver may differ depending on your LAN device model.
To add a network component, click Install in the screen shown in the figure above. You can add
clients, services and protocols.
NOTE
■ The LAN device driver may differ depending on your LAN device model.
To add a network component, click Install on the screen shown in the figure above. You can add
clients, services and protocols.
NOTE
■ When not using DHCP ask your network administrator for the IP address.
