7. Operation via menu functions
7.1 Short overview menu functions
▶
Press [MENU/◀▶] button to start
▶
One accesses the next menu level via the [MENU/◀▶] button.
▶
Press and hold the [MENU/◀▶] button to go back one menu level. To do this, hold
down the [MENU/◀▶] button until the arrow turns to the left and release the button
immediately. The return is automatic and does not need to be confirmed.
▶
Select the setting with [LIGHT/▼] or [ZERO/▲].
▶
Confirm the selection with the [MENU/◀▶] button.
Menu level 1 Menu level 2 Menu level 3
Measure mode
Unit
bar (presetting)
mbar
psi
kg/cm²
MPa
kPa
1)
mPa
1)
Pa
1)
mmH₂O
1)
mH₂O
1)
inH₂O
1)
ftH₂O
1)
mmHg
1)
inHg
1)
kN/m²
1)
m
1) 2)
cm
1) 2)
mm
1) 2)
feet
1) 2)
inch
1) 2)
User-defined unit 1
1)
User-defined unit 2
1)
7. Operation via menu functions
1) Only in combination with accuracy 0.25 % FS
2) Units are only displayed if the setting Level = is set to On.
