7.2.4 Ta re
The Tare function makes it possible to enter an offset value for the pressure value.
If a value other than 0 is entered and tare is “ON”, tare is activated and the pressure
value in the main display changes immediately.
The Tare value entered is added to the pressure value.
For example, if a value of 1.000 is entered, this value will be added to the measured
pressure value. If -2.589 is entered, this value is also added to the measured pressure
value.
To change, activate or deactivate the tare function, proceed as follows under “Menu” /
“Measure mode” / “Tare”:
1. With the [LIGHT/▼] button or [ZERO/▲] button, select the desired function.
2. Confirm the selection with the [MENU/◀▶] button.
⇒
With ON or OFF, the instrument moves back one menu level.
⇒
If OFFSET is selected, an input field for the offset number appears. (The entry is
made from left to right.)
3. Use the [LIGHT/▼] button or [ZERO/▲] button to select the number and use the
[MENU/◀▶] button to jump one digit to the right.
To accept the set tare value, press the [MENU/◀▶] button repeatedly until the
instrument jumps back one menu level.
Press the [HOME] button in order to exit the menu.
The tare value depends on the technical units of measurement and the resolution
selected for the display.
Both positive and negative Tare values can be entered.
Resolution and unit are identical to the main display.
If the Tare function is activated, the Tare symbol will be displayed.
The Tare value input is limited to the measuring range. The limitation is
calculated depending on the measuring range and unit. If a measured value
due to a tare setting exceeds the value that can be indicated, “-----” is
displayed.
