WIKA FSD-3 User Manual

19WIKA operating instructions flow switch, model FSD-3
EN
14153887.01 09/2016 EN/DE/FR
Display mode
▲ ▼
Long pressing of the “MENU” key
Programming mode
▲ ▼
SP1 / FH1
Value Flow: 5 ... 100 % ; temperature -15 ... +85 °C
▲ ▼
RP1 / FL1
Value Flow: 0 ... 95 % ; temperature -20 ... +80 °C
▲ ▼
SP2 / FH2
Value Flow: 5 ... 100 % ; temperature -15 ... +85 °C
▲ ▼
RP2 / FL2
Value Flow: 0 ... 95 % ; temperature -20 ... +80 °C
▲ ▼
EF
RES
Yes / No Reset to factory settings
▲ ▼
DS1
Value 0 ... 50 s
▲ ▼
DR1
Value 0 ... 50 s
▲ ▼
DS2
Value 0 ... 50 s
▲ ▼
DR2
Value 0 ... 50 s
▲ ▼
OU1
PARA HNO, HNC, FNO, FNC
▲ ▼
OU2
PARA HNO, HNC, FNO, FNC
▲ ▼
UNIT
Unit °C, °F
▲ ▼
SETF
Min Value Adjustment: Minimum ow
▲ ▼
Max Value Adjustment: Maximum ow
SETT (option)
Min Value Measuring range scaling: Minimum temperature value
▲ ▼
Max Value Measuring range scaling: Maximum temperature value
DISM
PARA Flow, Temp, SP1, RP1, SP2, RP2, O
▲ ▼
DISR
Yes / No Rotate display by 180°
▲ ▼
PAS
Value Password
▲ ▼
TAG
Value TAG name (16 ASCI characters)
▲ ▼
END END
▼ ▼ ▼ ▼
Display mode
Menu
5. Commissioning, operation
