18 WIKA operating instructions flow switch, model FSD-3
EN
14153887.01 09/2016 EN/DE/FR
5. Commissioning, operation
5.5 Parameter
Parameter Description
SP1/SP2 Hysteresis function: Switch point, switching output (1 or 2)
FH1/FH2 Window function: Window high switching output (1 or 2)
RP1/RP2 Hysteresis function: Reset point, switching output (1 or 2)
FL1/FL2 Window function: Window low switching output (1 or 2)
EF Extended programming functions
RES Reset the set parameters to the factory settings
DS1/DS2 Switch delay time, which must occur without interruption before any electrical signal change occurs (SP1 or SP2)
DR1/DR2 Switch delay time, which must occur without interruption before any electrical signal change occurs (RP1 or RP2)
OU1 / OU2 Switching function switching output (1 or 2)
HNO = hysteresis function, normally open
HNC = hysteresis function, normally closed
FNO = window function, normally open
FNC = window function, normally closed
UNIT Unit switching
SETF Adjustment: Minimum and maximum ow
SETT (option) Measuring range scaling of 4 ... 20 mA temperature output
“Min” determines at which temperature the output signal is to be 4 mA.
“Max” determines at which temperature the output signal is to be 20 mA.
DISM Display value in display mode
FLOW = current ow value; TEMP = current temperature value; OFF = display o;
SP1/FH1 = function switch point 1, RP1/FL1 = function reset point 1,
SP2/FH2 = function switch point 2, RP2/FL2 = function reset point 2
DISR Rotate display by 180°
PAS Password input, 0000 = no password; password input digit by digit
TAG Input of a 16-gure alphanumeric measuring point number
