WIKA Phase-Out PSD-3 Series User Manual

11WIKA operating instructions pressure switch, model PSD-3x
EN
11430486.07 04/2015 EN/DE/FR/ES
3. Specications
Switching current
■
without IO-Link: max. 250 mA
■
with IO-Link: SP1 max. 100 mA, SP2 max. 250 mA
Settling time
Analogue signal: 3 ms
Switching output: ≤ 10 ms (20 ms with IO-Link)
Load
Analogue signal 4 ... 20 mA: ≤ 0.5 kΩ
Analogue signal DC 0 ... 10 V: > 10 kΩ
Service life
100 million switching cycles
3.4 Voltage supply
Power supply
DC 15 ... 35 V
Current consumption
Switching outputs with
■
Analogue signal 4 ... 20 mA: 70 mA
■
Analogue signal DC 0 ... 10 V: 45 mA
■
without analogue signal: 45 mA
IO-Link option causes a deviating current consumption
Total current consumption
■
without IO-Link: max. 600 mA including switching current
■
with IO-Link: max. 450 mA including switching current
