3. Specications
3. Specications
3.1 Measuring ranges
Gauge pressure
bar 0 ... 1
1)
0 ... 1.6
1)
0 ... 2.5 0 ... 4 0 ... 6 0 ... 10 0 ... 16 0 ... 25
0 ... 40 0 ... 60 0 ... 100 0 ... 160 0 ... 250 0 ... 400 0 ... 600
psi 0 ... 15
1)
0 ... 25
1)
0 ... 30
1)
0 ... 50 0 ... 100 0 ... 160 0 ... 200 0 ... 300
0 ... 500 0 ... 1,000 0 ... 1,500 0 ... 2,000 0 ... 3,000 0 ... 5,000 0 ... 8,000
Absolute pressure
bar 0 ... 1
1)
0 ... 1.6
1)
0 ... 2.5 0 ... 4 0 ... 6 0 ... 10 0 ... 16 0 ... 25
psi
0 ... 15
1)
0 ... 25
1)
0 ... 30
1)
0 ... 50 0 ... 100 0 ... 160 0 ... 200 0 ... 300
Vacuum and +/- measuring range
bar -1 ... 0
1)
-1 ... 0.6
1)
-1 ... 1.5 -1 ... 3 -1 ... 5 -1 ... 9 -1 ... 15 -1 ... 24
psi -14.5 ... 0 -14.5 ... 15 -14.5 ... 30 -14.5 ... 50 -14.5 ... 100 -14.5 ... 160 -14.5 ... 200 -14.5 ... 300
The given measuring ranges are also available in kg/cm
2
and MPa.
1) Not available for PSD-31.
Overpressure limit
2 times
1.7 times for the relative pressure measuring ranges 160 psi, 1,000 psi and 1,500 psi
3.2 Display
14-segment LED, red, 4-digit, 9 mm character size
Display can be turned electronically through 180°
Update (adjustable): 100, 200, 500, 1,000 ms
