WIKA Phase-Out PSD-3 Series User Manual

5WIKA operating instructions pressure switch, model PSD-3x
EN
11430486.07 04/2015 EN/DE/FR/ES
Explanation of symbols
WARNING!
... indicates a potentially dangerous situation which can result in serious injury or death if not
avoided.
CAUTION!
... indicates a potentially dangerous situation which can result in light injuries or damage to
the equipment or the environment if not avoided.
Information
… points out useful tips, recommendations and information for ecient and trouble-free
operation.
Abbreviations
U
+
Positive power terminal
U- Negative power terminal
S
+
Analogue output
SP1 Switch point 1
SP2 Switch point 2
C Communication with IO-Link
MBA Start of measuring range
MBE End of measuring range
1. General information

WIKA Phase-Out PSD-3 Series Specifications

General

Brand	WIKA
Model	Phase-Out PSD-3 Series
Category	Switch
Language	English
