WIKA operating instructions RTD and TC, intrinsically safe designs
3345267.08 06/2011 GB/D
17
GB
6.2.2 Resistance thermometer with cable or connector
Without
connector
Lemosa
connector
3366036.02
1 x Pt100
2-wire
1 x Pt100
3-wire
1 x Pt100
4-wire
2 x Pt100
2-wire
2 x Pt100
3-wire
red
red
red
red
red
red
red
red
white
white
white
white
Connector
(male)
View from the front
Socket (female)
View from the front
white
white
black
black
black
yellow
yellow
3160629.06
6. Commissioning, operation
