WIKA operating instructions process transmitter, model UPT-2x
EN
14381795.02 04/2020 EN/DE/FR/ES
Supplementary documentation:
▶
This additional information for hazardous areas applies in conjunction with the
operating instructions „Process transmitter, model UPT-2x“ (article number 14068347).
1. Ex marking
1. Ex marking
DANGER!
Danger to life due to loss of explosion protection
Non-observance of these instructions and their contents may result in the
loss of explosion protection.
▶
Observe the safety instructions in this chapter and further explosion
instructions in these operating instructions.
▶
Observe the information given in the applicable Ex certificate and the
relevant regulations for installation and use in hazardous areas.
Check whether the classication is suitable for the application. Observe the relevant
national regulations.
Approval Marking
ATEX Zone 1 gas
Zone 1 mounting to zone 0 gas
Zone 2 gas
Zone 21 dust
Zone 21 mounting to zone 20 dust
[II 2G Ex ia IIC T4/T5/T6 Gb]
[II 1/2G Ex ia IIC T4/T5/T6 Ga/Gb]
[II 3G Ex ic IIC T4/T5/T6 Gc]
[II 2D Ex ia IIIC T135 °C Db]
[II 1/2D Ex ia IIIC T135 °C Da/Db]
IECEx Zone 1 gas
Zone 1 mounting to zone 0 gas
Zone 2 gas
Zone 21 dust
Zone 21 mounting to zone 20 dust
[Ex ia IIC T6 ... T3 Gb]
[Ex ia IIC T6 ... T3 Ga/Gb]
[Ex ia IIC T6 ... T3 Gc]
[Ex ia IIIC T135 °C Db]
[Ex ia IIIC T135 °C Da/Db]
Approval ratings ATEX and IECEx
■
Gases and mist Mounting to zone 0 (EPL Ga/Gb)
Installation in zone 1 (EPL Gb) and zone 2 (EPL Gc)
■
Dusts Mounting to zone 20 (EPL Da/Db); installation in zone 21 (EPL Db)
For further certicates and approvals, see local website.
