MOUNT SHOE - MOUNT THE WILCOX SHOE TO THE EOTECH
MAGNIFIER
If permanent installation is desired, apply a drop of Loctite271
to the threads of the screws and set aside.
Attach the bottom of the
Wilcox Shoe to the top of
the EOTech Magnifier (not
provided), aligning the screw
holes.
Tighten the screws (1) using a
flathead screwdriver.
1
