22 January, 2024 6 Rev. A-4
OPERATION
PIVOT - STOW AND DEPLOY THE FLIP MOUNT
The Flip Mounts for the
EOTech G23 feature a
force-to-overcome tilt
mechanism. To pivot the Flip
Mount between the deployed
and stowed positions, simply
tilt the mount with enough
force to overcome the
resistance of the mount.
DEPLOYED
(RH FLIP MOUNT DEPICTED)
