11
the receiver with a finger. To remove depleted batteries, pull up
on the fabric strip. IMPORTANT: If Alkaline (or non-recharge-
able) batteries are being installed, slide the battery selection
switch above the battery compartment to the “Alkaline” posi-
tion. If installing NiMH (or rechargeable) batteries, slide the
battery selection switch to the “NiMH” position. Press the bat-
teries into place over the fabric strip. Be sure to observe proper
polarity (+/-). Damage due to improper battery installation may
void the warranty on the product. Close the battery door. When
the sound becomes weak or distorted, replace or recharge the
batteries. NOTE: The ON indicator will illuminate RED to
indicate low battery.
CONNECTING EARPHONES
Plug the earphone into the “EAR” jack on the top of the unit.
Only monophonic earphones will operate properly. If stereo
headphones are used, sound will be heard only in one side of
the headphones. Williams Sound evaluates each earphone and
headphone used with the PPA R35 receiver; we can only assure
optimum performance when Williams Sound earphones and
headphones are used.
O
PERATING THE RECEIVER
NOTE: First, make sure the PPA T27 transmitter is on and
receiving good audio input. Check to make sure the receiver is
on the same frequency as the transmitter. If the R35 receiver
needs to be re-tuned (most Williams Sound receivers are set at
the factory at 72.9 MHz), see page 12 for frequency change
instructions.
Turn the receiver on by rotating the volume control knob clock-
wise. The receiver’s ON indicator should illuminate green.
Adjust the volume control for your comfort. To turn the receiv-
er off, rotate the volume control knob counter-clockwise until it
clicks off. The receiver’s ON indicator should go off.
To maximize battery life, remember to turn the receiver off
when it’s not in use.
