Williams 6508632 - Page 38

Replacement Parts List
38
REPLACEMENT PARTS FOR MODELS 5008631; 5008632; 5508231; 5508232; 6508631 and 6508632
Ref.
Number
Description
PART NO. FOR MODEL
5008631
5008632
5508231
5508232
6508631
6508632
1
Outer Casing, Less Front Panel
7C55-4
7C55-4
7C55-3
7C55-3
7C55-3
7C55-3
2
Inner Liner
11B46
11B46
7B79
7B79
7B79
7B79
3
Heating Element
7C116
7C116
7C68
7C68
7C117
7C117
4
Relief Opening Pan
7B108
7B108
7B107
7B107
7B108
7B108
5
Top Front Panel
7B126
7B126
7B126
7B126
7B126
7B126
6
Center Front Panel
11C60
11C60
11C59
11C59
11C59
11C59
7
Switch Box
11B05
11B05
11B05
11B05
11B05
11B05
8
Limit Switch
P200300
P200300
P296001
P296001
P309600
P309600
9
Selector Switch
P213400
P213400
P296201
P296201
P296201
P296201
10
Fan Switch
P200200
P200200
P200200
P200200
P200200
P200200
11
Bottom Front Panel
11B103
11B103
11B103
11B103
11B103
11B103
12
Element Base Gasket
P026500
P026500
P026500
P026500
P026500
P026500
13
Fan Shroud
7B106
7B106
7B106
7B106
7B106
7B106
14
Relief Pan Gasket
P028300
P028300
P028300
P028300
P028300
P028300
15
Vent Cover
7B12
7B12
7B12
7B12
7B12
7B12
16
N/A
-
-
-
-
-
-
17
Flue Collar Gasket
P027100
P027100
P027100
P027100
P027100
P027100
18
Header
7B114
7B114
7B57
7B57
7B57
7B57
19
Limit Switch
P323379
P323379
P323379
P323379
P323379
P323379
20
Switch Box Cover
11C68
11C68
11C68
11C68
11C68
11C68
21
Lower Element Base Angle
7A117
7A117
7A117
7A117
7A117
7A117
22
Transformer, 115V/24V
P024200
P024200
P024200
P024200
P024200
P024200
23
Junction Box
7B29
7B29
7B29
7B29
7B29
7B29
24
Internal Wires (All Except Ign.
Control)
5008631
5008632
5508231
5008232
6508631
6508632
25
Vibration Isolators (4 Req.)
P022800
P022800
P022800
P022800
P022800
P022800
26
Motor Support (2 Req.)
7B46
7B46
7B46
7B46
7B46
7B46
27
Motor
P062101
P062101
P062101
P062101
P321601
P321601
28
Motor Fan Blade
P200600
P200600
P200600
P200600
P014300
P014300
29
Deflector Baffle Handle
11C63
11C63
11C63
11C63
11C63
11C63
30
31
* Vent Enclosure Side (2 Req.)
* Vent Enclosure Front
9812
9812
9812
9812
9812
9812
30
31
* Vent Enclosure Side (2 Req.)
* Vent Enclosure Front
9824
9824
9824
9824
9824
9824
32
33
34
35
36
* Rear Grille, Two-Way
* Rear Outer Boot, 10" Long
* Plaster Ground
* Rear Inner Boot, 10-3/4" Long
* Damper
6801
6801
6801
6801
6801
6801
32
33
34
35
36
* Rear Grille, Two-Way
* Rear Outer Boot, 7/8" Long
* Plaster Ground
* Rear Inner Boot, 1-5/8" Long
* Damper
6802
6802
6802
6802
6802
6802
37
37
* Diffusing Grille Kit (Two-Way)
* Diffusing Grille Kit (One-Way)
6703
6704
6703
6704
6703
6704
6703
6704
6703
6704
6703
6704
38
39
40
41
* Side Inner Boot, 10-3/4" Long
* Side Outer Boot, 10" Long
* Side Plaster Ground
* Side Grille
6701
6701
6701
6701
6701
6701
38
41
* Side Inner Boot, 1" Long
* Side Grille
6702
6702
6702
6702
6702
6702
*
* Trim Strip Kit (not shown)
4701
4701
4701
4701
4701
4701
*
* Oval B/W Vent Kit (not shown)"
9901
9901
9901
9901
9901
9901
