5 Product information
5.1 Type key
Example: Modbus RTU CIF module
CIF module
“Communication Interface” module
Modbus RTU
Model/function identifier:
Modbus RTU = RS485 interface, Modbus RTU pro-
tocol
BACnet MS/TP = RS485 interface, BACnet MS/TP
protocol
Table2: Type key
5.2 Technical data
Technical data
General data
Terminal diameter (finely stranded without end
sleeves)
1.5mm
²
(max.)
Electric circuit
SELV, galvanically isolated
Ethernet interface according to IEEE 802.3
Interface
2 (integrated switch)
Interface type
Auto MDI-X
Connection type
10BASE-T, 100BASE-TX (half/full duplex, auto-
negotiation)
Connection type
RJ45 bush (shielded)
Cable length
100m (max.)
CAN interface according to ISO 11898-2
Cable length
200m (max.)
Termination resistor
120Ω (integrated, switchable)
RS485 interface as per EIA/TIA (RS) 485-A
Load (unit load)
*
1/8 unit load
Input voltage
Max. 12 V (differential A-B)
Termination resistor
120Ω (integrated, switchable)
TP/FT-10 interface
Cable type
J-Y(St) Y 1x2x0,8mm / CAT 5 AWG 22
