14 WILO SE 09/2014
5. Product information
5.1 Type key
5.3 Scope of delivery
Pump with
• 10 metre connecting cable with mains plug
• Connected float switch (design-A)
• Turbulator (TSW)
• Hose connection (Ø 32 mm / R 1)
• Non-return valve
• Installation and operating instructions.
5.4 Accessories
Accessories must be ordered separately (see
catalogue):
• Switchgear for 1 or 2 pump operation
• External monitoring devices / tripping unit
• Level control (e.g. flow switch)
• Accessories for transportable wet sump installa-
tion (e.g. hose couplings, hoses, etc.).
• Accessories for stationary wet sump installation
(e.g. check valves, non-return valves, etc.).
Example: TS 32/9 A -10M KA,
TSW 32/8 A -10M KA
TS
Series: T = submersible pump
S = wastewater
W with turbulator
32
Nominal diameter of pressure port [mm]:
32 = Rp 1¼
/8 Max. delivery head [m] when Q=0m³/h
A
A =with float switch
-10M KA Length of mains connecting cable [m]: 10
5.2 Technical data
Mains voltage:
1~230 V, ± 10 %
Mains frequency: 50 Hz
Protection class: IP 68
Insulation class: B
Speed: 2900 rpm (50 Hz)
Max. current consumption: See name plate
Power consumption P1: See name plate
Max. flow rate: See name plate
Max. delivery head: See name plate
Operating mode: 4000 operating hours a year
Operating mode S3 (optimum):
Intermittent duty, 30 %
(3.0 min. operation, 7.0 min. interval).
Recommended switching frequency: 20/h
Max. switching frequency: 50/h
Free ball passage: 10 mm
Nominal diameter of the pressure port: Ø 32 mm (Rp 1¼)
Admissible fluid temperature:
briefly 3 min.:
+3 to 35 °C
90 °C
Max. submersion depth: 10 m
Flat suction up to: 8 mm (TSW: 18 mm)
