Assembly Sheet For the Anchor Bolts
B-2 WILO EMU 3.0
1 Drill the holes as shown in table 1 and the following drawing.
Note: The quality of the fastening depends on how well the anchor bolts
are correctly seated!
HIS-RN M16x170 170mm 170mm 28mm 210mm
Name
Minimum
thickness t
b
Torque T
inst
Max. thickness of the part to be
fastened
HAS-R M8x80/14 130mm 10Nm 14mm
HAS-R M12x110/28 160mm 40Nm 28mm
HAS-R M16x125/38 175mm 80Nm 38mm
HAS-R M16x125/108 175mm 80Nm 108mm
HAS-E-R M20x170/48 220mm 150Nm 48mm (without hexagon head)
HAS-E-R M24x210/54 260mm 200Nm 54mm (without hexagon head)
HIS-RN M16x170 220mm 80Nm (internal thread M16)
Table B-2: Dimensions and tightening torque values
Name Rod length
Drill hole
depth
Drill hole
diameter
Min. distance
from edge a
r
Table B-1: Dimensions and tightening torque values
a
r
a
r
t
b
