Assembly Sheet For the Anchor Bolts
E:\shares\Baprod\BA\subtec_m\appendix\us\general\anchor_bolts.fm B-3
2 Carefully and thoroughly clean the holes using a brush and bellows.
3 Insert the grout cartridge carefully into the hole. Any air bubbles must face outwards. If the
drilled hole is too deep or broken at the edges, you may need to use more than one grout
cartridge.
4 Using a suitable insertion tool, turn and knock the anchor bolt into the mortar cartridge until
it reaches the insertion depth marking (1). The gap between the anchor bolt and the back-
ground structure must be completely filled with grout.
1
