Wilo fluidcontrol ek User Manual

ENGLISH
12 (55)
1 General
Installation and service by qualified personnel only!
1.1 Application
The electronic control system Wilo-Fluidcontrol (... EK) can be screw-attached
to water supply and pressure booster pumps. It enables the automatic
operation of these pumps without use of a separate pressure vessel.
1.2
Product Information
1.2.1 Technical Data
Flow medium clean water free of suspended matter
Max. capacity 10 m
3
/h
Max. working pressure 10 bar
Switch on pressure 1.5 - 2.7 bar
Max. water temperature: 60° C
Power supply: Single phase 1~ 220-250V,
50-60 Hz
F.L.C. max. 10 A
Enclosure: IP 65
Connections suction/discharge 1" BSP
The shut-off head generated by the applicable pump must be approx. 0.5 bar
higher than the 2.2 bar switch-off pressure.
State all name plate data when ordering spare parts.
2 Safety Notes
These instructions contain basic rules on safety which must be strictly adhered
to on installation and operation. It is therefore imperative for the Installer and
the Operator to read these instructions prior to installation and commissioning.
Please observe, not only the general safety references listed under the main
heading SAFETY NOTES, but also those added to and specially highlighted
under the ensuing headers.
