Transportation and storage en
Installation and operating instructions Wilo Motor T 17.3, 20.2:, EMU FA, Rexa SUPRA, Rexa SOLID 63
Example: Wilo-Rexa SOLID-Q10-768A
8
Characteristic curve number
A
Material version:
A = Standard version
B = Corrosion protection 1
D = Abrasion protection 1
X = Special configuration
4.8.4 Motor type key: T motor
Example: T 20.2M-4/32GX-P5
T
Surface-cooled motor
20
Size
2
Configuration version
M
Shaft design
4
Number of poles
32
Package length in cm
G
Seal version
X
Ex-rated
P
Motor design:
- None = Standard asynchronous motor
- E = Highly efficient asynchronous motor
- P = Permanent magnet motor
5
IE efficiency class (based on IEC 60034-30):
None = IE0 to IE2
3 = IE3
4 = IE4
5 = IE5
4.9 Scope of delivery
Standard pump
ƒ Pump with bare cable end
ƒ Installation and operating instructions
Configured pumps
ƒ Pump with bare cable end
ƒ Cable length as per customer request
ƒ Mounted accessories, e.g. external pencil electrode, pump support foot, etc.
ƒ Installation and operating instructions
4.10 Accessories
ƒ Suspension unit
ƒ Pump support foot
ƒ Special versions with Ceram coatings or special materials
ƒ External pencil electrode for sealing chamber control
ƒ Level control devices
ƒ Fixation accessories and chains
ƒ Switchgear, relays and plugs
5 Transportation and storage
5.1 Delivery
After receiving the shipment, this must be checked immediately for defects (damage,
completeness). Defects must be noted on the freight documentation! Furthermore, de-
fects must be notified to the transport company or the manufacturer immediately on
the day of receipt of shipment. Subsequently notified defects can no longer be asser-
ted.
