Wilo HiControl 1 User Manual

29
English
WILO SE
Working data
Pressure threshold below which the
pump will restart.
1.5 bar
Flow rate threshold below which the
pump will stop.
95 l/h
5.2 Dimension drawing
Fig. 2: Side view - manometer side
Fig. 3: Front view
Fig. 4: Top view
5.3 Product description (Fig. 5)
1 - Discharge port, 1"
2 - “Power on” indicator light
3 - “Safety system activated” indicator light
4 - “Pump operating” indicator light
5 - RESET button
6 - Connection cables with cable ends depending on version (Fig. 7 or 8)
Fig. 7: Mains cable
(HiControl 1-ARS version)
Fig. 8: Mains cable with female shockproof plug
(HiControl 1-EK version)
5.4 Scope of delivery
HiControl 1
• HiControl 1 automatic pump control system, no cord
• Bag containing two threaded cable connections
• Instruction manual
HiControl 1-EK
• HiControl 1-EK automatic pump control system, mains cable with female
shookproof plug
• Bag containing two threaded cable connections
• Instruction manual
HiControl 1-ARS
• HiControl 1-ARS automatic pump control system, mains cable with Australian plug
• Bag containing two threaded cable connections
• Instruction manual
6 Description and function
• The HiControl 1 automatic pump control system is a device which protects the
pump in the event of low water. It also controls the starting and stopping of the
pump based on the system pressure/flow conditions.
• When a tap is turned on, the pressure in the system falls, and the pump
