Wilo Stratos PICO-Z User Manual

Installation and operating instructions Wilo-Stratos PICO-Z
23
English

Information about
these instructions
These instructions facilitate safe and efficient pump
operation. Read these instructions before commencing
work and keep them in an accessible place at all times.
For safe pump operation, observe these instructions and
the data and markings on the pump.
Observe local regulations where the pump is installed.
Highlighting
instructions
Safety instructions used in this manual:
Tips and information:
1 Overview
Product Wilo-Stratos PICO-Z (Fig. 1)
1 Pump housing with screwed connections
2 Housing screws
3 Glandless pump motor
4 Rating plate
5 Thermal insulation shell
6 Control module
7Display
8 Operating knob
9 Wilo-Connector, electrical mains connection
Danger: Indicates a danger to life due to electrical
current.
Warning: Indicates a possible danger to life or risk
of injury.
Caution: Indicates a possibility of property dam-
age.
Note: Highlights tips and information.

Wilo Stratos PICO-Z Specifications

General

Max. Operating Pressure	10 bar
Insulation Class	F
Max Ambient Temperature	+40 °C
Connection Size	1"
Energy Efficiency Index (EEI)	0.20
Pumped Liquid	Water
Power Supply	230 V, 50 Hz
Installation Length	180 mm
