Installation and operating instructions Wilo-DrainLift Con 17
English
5 Product information
5.1 Type key
5.3 Scope of delivery
• Condensate lifting unit, ready for connection
• Condensate drain off with integrated non-return valve
• Mains cable with plug (2 m)
• Alarm cable with stripped cable ends (1 m)
• Hose for pressure side (5 m)
• Wall mounting material (drill template, screws, dowels)
• Installation and operating instructions
• Inlet adapter DN 40/30
Example: Wilo-DrainLift Con
DrainLift = lifting unit
Con = condensate
5.2 Technical data
General data
Connected voltage 1 ~ 230 V
Frequency 50 Hz
Connecting cable Mains cable: 2 m
Alarm signal: 1 m
Connected load 60 W
Protection class IP 20
Nominal current 0.6 A
Operating mode S3 30%
(Intermittent operation, 3 min., 7 min. operation,
pause)
Approved medium Condensate water
Permissible fluid temperature max. 50 °C
Delivery head max. 5.5 m
Sound pressure level
< 50 dBA at 1 m
Tank volume 1.2 l
Weight approx. 2.1 kg
Dimensions Width: 210 mm
Height: 120 mm
Depth: 167 mm
Inlet connections Diameter 30 mm
Diameter 19 mm
Discharge connection Diameter 10 mm
