Adjustable Gain DB Pro Specications
FCC ID: PWO271265
Dual-Band Wireless
800/1900 MHz Specications
Model Number 271265
Antenna connectors SMA Female
Antenna impedance 50 ohms
Dimensions 5.7 x 4.2 x 1.5 inch (14.0 x 10.8 x 3.9 cm)
Weight 0.48 lbs (0.22 kg)
Frequency 824-894 MHz / 1850-1990 MHz
Passband Gain 75 dB
Power Output 800 MHz 1900 MHz
Max Power output for single cell phone (reverse link) 30.8 dBm 30.5 dBm
Max Power output for single received channel (foward link) 26.0 dBm 25.2 dBm
Noise Figure (forward link) 3.5 dB nominal
Noise Figure (reverse link) 5.5 dB nominal
Isolation (reverse link/forward link) > 90 dB
Power Requirements 110-240 V AC, 50-60 Hz, 8 W
