Warnings and Recommendations
Warning: Verify that both the outside antenna and the adapter extension
cable are connected to the amplifi er before powering up the
amplifi er.
Warning: RF Safety: In-vehicle - The outside antenna must be installed
with a separation of at least 16 inches from any of the vehicle’s
occupants or nearby persons and must not be located or
operating in conjunction with any other antenna or amplifi er. Use
of a cellular amplifi er with an antenna gain higher than 5.12 dBi
is in violation of FCC regulations, for which the offender is fully
liable. All Wilson mobile antennas are 5.12 dBi or less.
Warning: RF Exposure Compliance: In-vehicle - All roof-mount antennas
should be centrally located on the roof of the vehicle. Glass-
mount antennas should be located in the middle of either the
front or back windshield. Mirror-mount antennas should be at
least six inches from the ground and leave at least 16 inches of
separation from any persons in or around the vehicle.
Warning: RF Safety: In-Building - The outside antenna must be installed
on an outdoor permanent structure with a separation of at least
20 feet from all persons during normal operation.
Lightning protection is recommended for all in-building installations.
NOTE: The aluminum casing of a Wilson amplifi er will adjust very quickly to the
ambient temperature of its environment. For example, in the summer, when the
inside of a car can reach 140 degrees Fahrenheit, the amplifi er temperature may
be 150 degrees or higher. The casing will be hot to the touch, similar to a metal
door handle or a steering wheel. Such high temperatures will not damage the
amplifi er, nor do they pose a fi re risk to the vehicle. As recommended in these
instructions, install the amplifi er in a location with adequate ventilation, such as
under the seat, in the trunk or under the dashboard. Keep the area free of items
that could block air fl ow to the amplifi er.
