24
Item Part
No. Number Description Qty
1 5517332 Casting, Head 1
2 5517376 Bolt, Hex, Shoulder 2
2-1 5517377 Spring 2
3 5517378 Rod, Cam Lock 2
4 5510250 Nut, Hex 2
5 5510251 Wrench, Hex Head 1
7 5510252 Screw, Set 1
8 5517379 Washer, External Tooth 1
10 5510253 Spindle 1
11 5510254 Bearing, Ball 2
12 5510255 Spacer 1
14 5510256 C-Ring 1
15 5510258 Screw, Set 1
16 5510259 Pin, Roll 1
26 5510261 Screw, Socket Head 1
27 5510262 Washer 1
28 5510263 Container, (includes #29) 1
29 5510263 Spring, Return 1
30 5510265 Screw, Socket Head 3
31 5510266 Seat, Spring 1
32 5510267 Pin, Spring 1
36 5513770 Washer, Rubber 1
37 5513771 Band, Quill 1
37A 5517380 Bolt, Hex, Shoulder 1
37B 5517381 Washer, Flat 2
37C 5517382 Nut, Hex 1
38 5513772 Nut, Lock 2
39 5513773 Bearing, Ball 1
40 5513774 Pin, Drift 1
41 5510268 Quill 1
42 5510269 Bearing, Ball 1
43 5510270 Spindle 1
44 5510271 Seal, Oil 1
45 5510272 Nut 1
46 5510273 Rod, Depth 1
48 5510274 Nut 1
49 5510275 Nut 1
50 5510276 Retainer 1
51 5510277 Pin, Spring 1
53 5510278 Scale, Depth 1
58 5510279 Screw, Round Head Cap 4
60 5510280 Key 1
61 5510281 Screw, Socket Head 3
62 5510282 Key 1
63 5510283 Shaft, Feed 1
66 5510284 Seat, Feed Shaft 1
Parts Listing — Spindle Components (All Models)
Item Part
No. Number Description Qty
67 5510285 Hub 1
68 5510286 Spoke 3
68A 5513515 Pickup, Magnetic 1
68B 5513687 Screw, Pan Head 2
69 5510287 Knob 3
69A 5517383 Plate, Adjustable 1
69B 5517384 Bracket, Mag. Pickup 1
69C 5513689 Screw, Cap 1
69D 5517385 Washer, Flat 1
69E 5517386 Nut, Hex 1
70 5517387 Screw 2
71 5511849 Cover 1
72 5513354 Screw 4
