Parts List – Saw Base - Model 7060 Semi-Automatic Cut-Off Band Saw
Ref Part
No. Number Description Qty
1 5512120 Bolt, Hex Cap (M12X35) 1
2 5512121 Washer, Lock (M12) 1
3 5512122 Pin 2
4 5512123 Rack 1
5 5512124 Bracket, Slide 1
6 5512125 Block, Rack 1
7 5512126 Screw, Set (M6X10) 1
8 5512127 Jaw, Vise (Left) 1
9 5512128 Washer (M12) 1
10 5512129 Washer, Lock (M12) 1
11 5512130 Bolt, Locking (M12X35) 1
12 5512131 Bolt, Hex Cap (M12X40) 2
13 5512121 Washer, Lock (M12) 1
14 5512128 Washer (M12) 1
15 5512173 Jaw, Vise (Right) 1
16 5512131 Bolt, Hex Cap (M12X40) 2
17 5512121 Washer, Lock (M12) 1
18 5512128 Washer (M12) 1
19 5512174 Scale, Angle 1
20 5512132 Block, Protractor Vise 1
21 5512133 Handle, Locking 1
22 5512134 Washer (1/2-inch) 1
23 5512135 Screw (3/8 x 1-inch) 3
24 5512136 Washer 3
25 5512137 Seat, Protractor 1
26 5512138 Stop Block, Protractor 1
29 5512139 Screw, Hex Cap, Socket 1
(M10X25)
30 5512140 Washer (M10) 1
27 5512141 Bolt, Hex Cap (M8X30) 1
28 5512142 Nut (M8) 1
31 5512143 Bracket, Adjusting 1
32 5512144 Plate, Switch Mounting 1
33 5512145 Switch Limit (5101) 1
34 5512146 Screw, Hex Cap, Socket 4
(M8X20)
35 5512147 Pin, Cylinder 1
36 5512148 Pin, Retaining 1
37 5512149 Washer, Lock (M10) 4
38 5512150 Bolt, Hex Cap (M10X30) 4
39 5512151 Cover, Cylinder 1
40 5512152 Pin (20MM) 1
41 5512153 Shaft, Pivot 1
42 5512154 Bearing, Needle (CB3020) 1
Ref Part
No. Number Description Qty
43 5512155 Bolt, Hex Cap (M8X25) 1
44 5512156 Washer, Lock (M8) 1
45 5512140 Washer (M10) 1
46 5512150 Bolt, Hex Cap (M10X30) 1
47 5512157 Spring 1
48 5512158 Cylinder Assembly,Hydraulic 1
49 5512159 Plate, Switch Stop 1
50 5512160 Washer, Lock (M6) 1
51 5512161 Screw, Hex Cap, Socket 1
(M6X12)
52 5512162 Plate, Hydraulic Mounting 1
(Top)
53 5512163 Switch Limit (5102) 1
54 5512146 Screw, Hex Cap, Socket 4
(M8X20)
55 5512128 Washer (M12) 3
56 5512164 Washer, Lock (M12) 3
57 5512165 Bolt, Hex Cap (M8X50) 3
58 5512166 Bolt, Hex Cap (M8X20) 4
59 5512167 Washer (M8) 4
60 5512168 Bracket, Pivot 1
61 5512169 Bracket, Limit Switch 1
62 5512156 Washer, Lock (M8) 2
63 5512171 Bolt, Hex Cap, Socket 2
(M8X20)
64 5512167 Washer (M8) 2
65 5512676 Hand Wheel Assembly 1
66 5512677 Seat, Lead Screw 1
67 5512175 Work Table 1
68 5512154 Bearing, Needle (CB3020) 1
69 5512128 Washer (M12) 1
70 5512155 Bolt, Hex Cap (M8X25) 2
71 5512178 Knob, Lock 1
72 5512179 Bolt, Hex Cap, Socket 1
(M8X25)
73 5512167 Washer (M8) 1
74 5512166 Bolt, Hex Cap (M8X20) 2
75 5512182 Seat, Lead Screw 1
76 5512183 Screw, Lead 1
77 5512213 Washer (M8) 2
78 5512156 Washer, Lock (M8) 2
79 5512184 Bolt, Hex Cap (M8X30) 2
80 5512185 Screw 4
Ref Part
No. Number Description Qty
81 5512186 Cover, Electrical Panel 1
82 5512187 Valve, Solenoid 1
83 5512188 Screw, Hex Cap, Socket 4
(M6X8)
84 5512189 Cover, Panel 1
85 5512190 Pump Assembly, Hydraulic 1
86 5512191 Motor 1
87 5512126 Screw, Set (M6X10) 1
88 5512192 Bolt, Hex Cap (M12X35) 2
89 5512164 Washer, Lock (M12) 2
90 5512128 Washer (M12) 2
91 5512194 Seat, Hydraulic 1
92 5512195 Cover, Panel 1
93 5512188 Screw, Hex Cap, Socket 4
(M6X8)
94 5512197 Plug, Drain (3/8-In. PT) 1
95 5512198 Nut, Hex (M12) 4
96 5512199 Bolt, Hex Cap (12X70) 4
97 5512200 Bolt, Hex Cap (M10X30) 2
98 5512201 Gauge, Coolant 1
99 5512140 Washer (M10) 2
100 5512202 Nut (M10) 2
101 5512203 Base 1
102 5512204 Knob, Lock 1
103 5512205 Bracket, Stop 1
104 5512206 Handle, Lock 1
105 5512207 Stop, Work 1
106 5512208 Rod, Stop 1
107 5512188 Bolt, Hex Socket Cap 4
(M6X8)
108 5512210 Cover, Panel 1
109 5512211 Washer, Lock 2
110 5512212 Screw, Pan Head (M6X16) 2
111 5512675 Pump, Coolant (1-Hp/3Ph) 1
112 5512214 Tube, Connecting 1
113 5512215 Switch (Saw Head Up) 1
114 5512216 Switch (Saw Head Down) 1
115 5512217 Screw, Pan Head (M5X8) 8
116 5512218 Panel, Control 1
117 5512219 Control, Cutting Pressure 1
118 5512220 Box, Control 1
119 5512221 Handle 1
To Next Page
