WIN Enterprises, Inc
11
MB-10510* Connector list
Connector
Dene
Connector
Dene
CN1
SYSTEM FAN
CN18
PS2 KB/MS (Pin Header)
CN2
CPU FAN
CN19
PCIe X1 Slot (Opon)
CN3
SYSTEM FAN
CN20
Power Switch
CN4
Wireless LAN LED (opon)
CN21
Status LED (Pin Header)
(Co-Layout with LED16)
CN5
USB Port 2 & 3 (Pin Header)
CN22
USB Port 0 & 1
CN6
VGA (Pin Header)
CN23
DC-IN (Pin Header)
(Co-Layout with CN31)
CN7
SATA Power Connector
CN24
LAN1
CN8
KEY PAD (Pin Header)
CN25
LAN2
CN9
LCM (Pin Header)
CN26
LAN3
CN10
SPI (Pin Header)
CN27
LAN4
CN11
SATA Connector
CN28
LAN5
CN12
COM2 (Pin Header)
CN29
LAN6
CN13
GPIO (Pin Header)
CN30
COM1(Console Port)
CN14
MINI-PCIe (Opon)
CN31
DC-IN (Power Jack)
(Co-Layout with CN23)
CN17
LPC (Pin Header)
* Motherboard
